DEENPU Lubricator Accessories
Wireline Rig-Up Tools
Home › Wireline Pressure Control Equipment › Lubricator Accessories
Product Overview
DEENPU supplies the complete range of lubricator accessories needed to rig up and operate a wireline lubricator string safely: union crossover adapters, floor blocks (hay pulleys), wireline clamps, wellhead connections, telescopic gin poles with load binders, rope blocks, pick-up clamps, and pump-in subs with plug valves.
Each item is rated for service and pressure, so your rig-up is only as strong as its weakest part — all DEENPU accessories are load or pressure tested accordingly and any combination of end connections is available.
Key Features
- Union crossover adapters (box up / pin & collar down), any combination
- Floor blocks in aluminium or composite for light weight
- Wireline clamps for lubricator handling and fishing
- Wellhead connections matching valve-to-tree interfaces
- Telescopic gin poles with load binder and chain
- Pump-in subs & plug valves rated above 5000 PSI with side ports
Technical Specifications
| Crossover Adapters | Union box up / union pin & collar down, any combination |
| Floor Block | Aluminium or composite pulley |
| Gin Pole | Telescopic, with load binder & chain |
| Pump-In Subs | >5000 PSI models with side ports for plug valves |
Dimensions & Technical Data
Lubricator accessories specifications
Quality & Testing
Every DEENPU Lubricator Accessories is manufactured under our API-compliant quality system: raw material traceability, 100% dimensional inspection, hydrostatic pressure testing and hardness verification before packing. Material certificates, inspection reports and API documentation are provided with shipment on request.
Applications
- Wireline / slickline lubricator rig-up and handling
- Live well intervention support equipment
- Hydrostatic testing of lubricator strings
Frequently Asked Questions
Q: What does a floor block do?
A: It brings the wireline down to a horizontal pull from the lubricator tree base, shifting the pull point off the top of the lubricator and reducing side loading.
Q: Why rate accessories for pressure as well as load?
A: Pump-in subs and plug valves see well pressure directly during injection or testing; DEENPU rates every pressure-containing accessory and marks it accordingly.
