Product Overview
The DEENPU X-Mas tree cap is the top connector fitted to the uppermost flange of the Christmas tree. Its principal function is to close and protect the tree bore while providing controlled access for pressure monitoring and wireline re-entry.
Construction is simple and field-friendly: a flanged body, a blanking plug with a provision to mount a pressure gauge, and a hammer nut for fast make-up. The bore interior is designed for quick installation and removal with standard rig tools.
Key Features
- Blanking plug accepts pressure gauge for tree bore monitoring
- Hammer nut for rapid installation / removal
- Flanged API 6A connection to tree top
- Sealed with O-ring and circlip retention
- 2000 – 10000 PSI working pressure
Technical Specifications
| Design Standard | API Spec 6A |
| Function | Tree bore closure + gauge access |
| Main Parts | Flanged body, blanking plug, hammer nut |
| Seals | O-ring, circlip retained |
| Working Pressure | 2000 – 10000 PSI |
Dimensions & Technical Data
X-Mas tree cap specifications
Quality & Testing
Every DEENPU API 6A X-Mas Tree Cap is manufactured under our API-compliant quality system: raw material traceability, 100% dimensional inspection, hydrostatic pressure testing and hardness verification before packing. Material certificates, inspection reports and API documentation are provided with shipment on request.
Applications
- Christmas tree top closure on producing wells
- Pressure monitoring point for the tubing bore
- Protection of tree threads during shut-in
Frequently Asked Questions
Q: Can I monitor tubing pressure through the tree cap?
A: Yes — the blanking plug has a gauge port, so a surface pressure gauge can be mounted directly in the cap.
Q: Which tree flanges does it fit?
A: Available for all standard API 6A tree top flange sizes; specify size and rating when ordering.
