OC-10 Triplex Pump
DEENPU OC-10 Triplex Pump delivers higher flow rates for larger BOP control systems requiring rapid accumulator recharge. Available in 10 to 25 HP configurations with 3,000 PSI maximum discharge pressure, the triplex design provides smoother flow and reduced pulsation compared to duplex alternatives.
Technical Specifications
| Parameter | Specification |
|---|---|
| Pump Type | Triplex positive displacement |
| Horsepower Range | 10 HP, 15 HP, 20 HP, 25 HP |
| Max Working Pressure | 3,000 PSI |
| Stroke Length | 2-1/4 inches |
| Rod Load | 2,000 lbs |
| Voltage Options | 230V, 460V, 380V, 575V |
Key Features
- Triplex design for smoother flow and reduced pulsation
- Higher flow rates than duplex equivalents
- 10-25 HP configurations for various flow requirements
- Multi-voltage motor options (230/460/380/575V)
- Complete repair kits and spare parts available
- Ideal for multi-function BOP control systems
Contact DEENPU for Orders & Technical Support
Email: SALES@DEENPU-MACHINERY.COM
WhatsApp: +86 158 0628 4962
